Gas radiant strip RayLine

Direct decentralised custom heating system for buildings:

with a minimum height of 4 metres
well insulated
with difficult access and circulation

Advantages

High combustion efficiency
Flexibility
Low operating costs
Lightweight
Easy maintenance
No paint
Safety (no gas inside the building)
Reliable
Aesthetic
Modular
Comfortable (even radiation distribution)
Silent running
Very low temperature gradient
Lower investment than for radiant hot water panels

Technical details

Description Parameters Data sheets References Request a quote

Description

8 models from 61 to 330 kW (from model RSB 110: 2 standard speeds, modulating on option, propane gas on option)
Burner can be installed indoors, outside on gable, on roof
Modular construction system enabling all geometrical configurations (45° and 90° elbows, direction change, Tee, mono-tube, dual tube, etc.)
Encasing panels for combustion unit in steel coated with “sea coast compatible” polyester paint
Combustion chamber guaranteed 5 years
Lateral evacuation connection (improved sealing – no condensate return)
Quick connection of all tubes by “Metu®” flanges allowing later modifications to the array (tertiary version)
Trapezoidal cross section of emission modules maximises the direct radiated flow (tertiary version)
Spiral radiant tubes in annealed aluminised steel, high emissivity, no paint (Lindab jointing technology)

APPLICATIONS

Parameters

TECHNICAL CHARACTERISTICS

		RSB 65	RSB 75	RSB 110	RSB 130	RSB 165	RSB 200	RSB 220	RSB 330
Heating value HHV	kW	61	75	61 - 106	78 - 134	100 - 162	126 - 192	132 - 220	198 - 330
Heating value LHV	kW	55	65	55 - 95	70 - 120	90 - 145	115 - 175	120 - 200	180 - 300
Combustion efficiency	%	92		92			92		92
G20 gas flow rate	m3/h	5.8	6.9	10.1	12.7	15.3	18.5	21.2	31.8
Gas connection		3/4’’		1’’			1’’		1’’1/4
Electrical supply		3 x 400 V + N - 50 Hz
Nominal current	A	1.7		3.2			4.6
Type of venting		B22
Venting diameter	mm	130

After a detailed study of your premises and requirements by our technical department we will be able to optimise the configuration and offer you the best solution

DIMENSIONS

		RSB 65	RSB 75	RSB 110	RSB 130	RSB 165	RSB 200	RSB 220	RSB 330
Width	mm	1 255		1 255			1 255		1 400
Width (overall)	mm	1 424		1 424			1 424		1 484
Height	mm	727		772			772		740
Box depth	mm	645		745			745		730
Depth (overall)	mm	1 074		1 174			1 174		1 130
Total mass	kg	116		119			134		156

DUAL TUBE / MONO-TUBE EMISSION MODULES

		RSB 65	RSB 75	RSB 110	RSB 130	RSB 165	RSB 200	RSB 220	RSB 330
Tube diameter	mm	250							315
Standard length	m	2 / 4
Height	mm	334							354
Dual tube / Mono-tube width	mm	772 / 452							850 / 535
Linear mass Dual tubes / Mono-tube	kg/m	17 / 11							20 / 13
Minimum strip length Dual tubes / Mono-tube	m	50 / 90	50 / 90	50 / 90	70 / 130	70 / 130	90 / 170	90 / 170	90 / 170
Maximum strip length
Dual tubes / Mono-tube	m	80 / 150	80 / 150	80 / 150	100 / 190	100 / 180	130 / 250	130 / 250	160 / 310
